Description

The AV-K-SWFK-IA EMG Biofeedback Stimulation Device is a modern rehabilitation system designed for muscle re-education, neuromuscular recovery, biofeedback training, and assisted electrical stimulation. It integrates EMG detection, NMES stimulation, ETS (EMG-triggered stimulation), and PAS (assisted stimulation) into a single, compact, and professional device—ideal for physiotherapy, neuro-rehab, and sports rehabilitation clinics.

Features

• Model: AV-K-SWFK-IA
• Certificate: ISO 13845 & CE
• EMG Biofeedback + Stimulation
• 4 NMES fixed stimulation protocols
• ETS (EMG-triggered stimulation) for active rehab
• PAS (Assisted stimulation) mode for weak muscles
• User-friendly interface with precise control

Technical Specifications

• Power Supply
  Adapter Input: AC 100V–240V, 50/60Hz
  Adapter Output: DC 5V, 3A
  Battery Output: DC 7.4V (portable & continuous use)
• Dimensions
  Host Unit: 375.5 × 135.5 × 26.6 mm
  Electrode Wire Length: 1300 mm
  Electrode Plate Diameter: 50 mm
• EMG Detection
  Biofeedback Threshold: 10–1000 μV
  Precise EMG sensing for real-time muscle activity monitoring.
• NMES Functional Electrical Stimulation
• ETS – EMG Triggered Stimulation
• Threshold: 10–1000 μV adjustable
• Frequency: 60 Hz
• Pulse Width: 300 μs
• Rise Time: 1 sec
• Fall Time: 1 sec
• Stimulation Duration: 6 sec
• Delay Time: 10 sec
• Output Peak Current: 0–60 mA (1 mA steps)
• Frequency: 18 Hz
• Pulse Width: 200 μs
• Output Peak Current: 0–60 mA adjustable

Advantages

• Improves motor control through EMG biofeedback
• Enhances neuroplasticity for stroke and nerve injury patients
• Promotes muscle activation and strength
• Enables active patient participation in therapy
• Adjustable stimulation parameters for different rehab stages
• Safe current output with precise intensity control
• Lightweight, portable design for clinic or bedside use
